Remote antenna for Chuyka detector of drones (3 m cables)
Remote antenna for the “Chuyka” drone detector (3 m) — an antenna designed to increase reception range and communication quality for electronic intelligence systems of the “Chuyka” drone detector and other compatible systems. Signal loss: 1.2 GHz — ≈0.95 dB; 3.3 GHz — ≈1.7 dB; 5.8 GHz — ≈2.25 dB.
In stock
368 $
* with VAT
* with VAT
Buy in one click
Add To Cart
Functions
Remote antenna for the Chuyka detector drone by BlueBird Tech is a modular, all-weather, high-performance platform whose specifications are optimized to provide maximum efficiency and stability for the electronic reconnaissance system (ERS) “CHUYKA”.
Thanks to the universal design and standardized interfaces, the platform is fully compatible with any other radio-electronic system operating in the corresponding bands.
MVA Universal enables relocation of antenna–feeder equipment away from the operator’s position, which critically improves reception quality, effectively mitigates local interference and expands coverage area.
Technical features and adaptability
Feeder line modularity
A key advantage of the Universal version is the use of industrial N-type female connectors on the enclosure. This allows the operator to select and quickly change the length and type of coaxial cable to minimize signal losses at the required distance.
Robust construction and protection
The platform housing is impact-resistant and provides a high degree of protection against environmental influences. It reliably protects the three integrated antennas from precipitation, dust and vibration during rapid deployment and long-term operation.
Three-channel integration
MVA Universal contains three independent antenna channels identical to those used in the base ERS “CHUYKA” unit, ensuring predictable reception characteristics in the bands:
Channel 1: 900−1800 MHz
Channel 2: 2870−4080 MHz
Channel 3: 4860−6060 MHz
Universal mounting and deployment
Equipped with four powerful magnets for instant fixation on metal surfaces. For stationary mounting, two mounting holes are provided (56 mm between centers) for secure attachment to a mast/pipe using a U-clamp (included). Additional service holes allow the use of ties or other fixation means on non-standard surfaces (wood, structures).
Global compatibility
Thanks to the standardized bands and the supplied cable with SMA-male connectors, MVA Universal can be easily integrated with any radio-electronic equipment that has SMA-female inputs and operates in the specified frequency ranges.
Technical characteristics:
MVA Universal Specifications
| Characteristic | Specification |
|---|---|
| Model name | MVA Universal |
| Number of channels | 3 |
| Operating bands |
900−1800 MHz |
| Antennas | Integrated |
| MVA connectors (external) | 3 × N-type female |
| Mounting | 4 × magnets, hole for U-clamp (56 mm) |
| Dimensions (W×H×D) | 120 × 220 × 240 mm |
| Weight (without cable) | 650 g |
Cable assembly specification 3 m cables (kit)
| Characteristic | Specification |
|---|---|
| Cable type | SLL-240-SF* |
| Cable length | 3 m |
| Connector to MVA | N-type male |
| Connector to ERS | SMA male |
| Signal loss (attenuation) over 3 m | – 1080−1800 MHz: ≈0.95 dB – 3000−4100 MHz: ≈1.7 dB – 4900−6100 MHz: ≈2.25 dB |
It Remote antenna for Chuyka detector of drones (3 m cables) includes:
- MVA Universal remote antenna module – 1 pc.
- Connecting cables 3 m – 3 pcs.
Delivery Methods
The primary delivery method is via Nova Poshta. We also ship via Ukrposhta or Meest Express.
Payment Methods
You can choose from several payment options:
-
Full Payment:
Pay for the order in full and collect it at the post office. -
Cash on Delivery:
Partial prepayment is required. If the item is not in stock, we start the production process. Afterward, we send the item and provide you with the tracking number. To collect the order from the post office, you will need to pay the remaining balance upon receipt. -
Partial Payment:
Reserve your order, and we begin the production process. Once your order is ready for shipment, you pay the remaining balance. We then send the item and provide you with the tracking number.
Return and Exchange Policy
Our company processes returns and exchanges in accordance with legal requirements.
Return Period:
Returns are accepted within 14 days of receipt (for items of proper quality).
Return Delivery:
Return shipping is carried out as per prior agreement.
In accordance with current legislation, you may return or exchange items of proper quality if:
- The item has not been used and shows no signs of use by the consumer, such as scratches, chips, scuffs, stains, etc.
- The item is fully complete, and the factory packaging is intact.
- The item retains its commercial appearance and consumer properties.
