Vishchun-5.8 Wireless Ground Repeater

“Vishchun-5.8” is a ground-based wireless repeater designed to extend the range of video transmission and FPV drone control. It is mounted on a telescopic mast and operates as an intermediate node between the operator and the UAV.

In stock

1 161 $
* with VAT

Add To Cart

Functions

“Vishchun-5.8” Ground Wireless Relay BlueBird Tech is a device designed to significantly increase the flight range of FPV drones (up to 25 km). The device is mounted on a mast and acts as a bridge between the operator and UAV, ensuring stable communication at distances unreachable by standard equipment.

Purpose:

The relay is designed to ensure reliable communication between the operator and the UAV over long distances. It receives the drone’s video signal, transmits it to the operator, and relays control signals. This allows operators to remain in a safe location while maintaining full control over the drone.

Key Advantages:

Wireless link to pilot: The pilot is not limited by cable length and can be located up to 1 km away from the relay mast (line of sight).
Mobility and autonomy: Thanks to its portable design and autonomous power supply, the relay can be easily mounted on any type of mast.
Extended range and reliability: Expands drone range up to 25 km depending on conditions.
Fast deployment: Ready for use within minutes with quick-mount brackets.
High-quality components: Uses premium parts for maximum reliability.
Stable operation in challenging environments: Maintains connection even with interference and obstacles.

Technical characteristics:

Parameter	Specification
Drone reception
VRX	5.8GHz SKYZONE Steadyview X 5G (4.990–5.945GHz)
Receiver sensitivity	–98 dBm ± 1 dBm
TX**	ERLS / TBS / LoRa — not included (max. 2 W)
Antenna connectors	SMA Female
Wireless transmission to pilot
VTX	ReadytoSky VTX 1.2G / 1.3G, 800 mW, 9 channels
VTX Antenna	TrueRC Singularity 1280 V2 (RHCP Bottom90), 1.9 dBi
RX	TBS Crossfire Nano
RX Antenna	TBS Diamond 915MHz, 2.88 dBi
Distance to operator	Up to 1 km (line of sight)
Power Supply	6S2P Battery
Operating Time	Up to 8 hours on 6S2P battery
Weight / Dimensions	(not specified)

It Vishchun-5.8 Wireless Ground Repeater includes:

#	Item	Qty	Note
1	“Vishchun-5.8” Ground Wireless Relay	1
2	Antenna 1.3GHz TrueRC 1280 V2 (RHCP Bottom), 1.9 dBi	1
3	Antenna TBS Diamond 915MHz, 2.88 dBi	1
4	Battery extension cable	1
5	Quick-mount bracket for mast (fits 40mm pipe)	1	To be confirmed
6	JR TX (transmitter) TBS Crossfire	1

Optionally can be added:

Optional: TX module (ERLS / TBS / LoRa) can be added if needed — not included or priced in.

Delivery Methods

The primary delivery method is via Nova Poshta. We also ship via Ukrposhta or Meest Express.

Payment Methods

You can choose from several payment options:

Full Payment:
Pay for the order in full and collect it at the post office.
Cash on Delivery:
Partial prepayment is required. If the item is not in stock, we start the production process. Afterward, we send the item and provide you with the tracking number. To collect the order from the post office, you will need to pay the remaining balance upon receipt.
Partial Payment:
Reserve your order, and we begin the production process. Once your order is ready for shipment, you pay the remaining balance. We then send the item and provide you with the tracking number.

Return and Exchange Policy

Our company processes returns and exchanges in accordance with legal requirements.

Return Period:
Returns are accepted within 14 days of receipt (for items of proper quality).

Return Delivery:
Return shipping is carried out as per prior agreement.

In accordance with current legislation, you may return or exchange items of proper quality if:

The item has not been used and shows no signs of use by the consumer, such as scratches, chips, scuffs, stains, etc.
The item is fully complete, and the factory packaging is intact.
The item retains its commercial appearance and consumer properties.

Other products in this category:

“Vishchun-K1B” control complex

“Vishchun-K1B” is a control complex designed to deploy a full-fledged ground communication node at the position, including “Vishchun-NS1”, “Vishchun-5.8”, and a telescopic mast. The main…

6 492 $

* price with VAT

Vishchun-P Aerial Repeater

“Vishchun-P” is an aerial repeater designed for mounting on a carrier drone, providing a stable video and control link for an FPV drone from an…

1 277 $

* price with VAT

“Promin-13” drone-repeater

“Promin-13” is a carrier drone for an aerial repeater, designed to create a stable, high-altitude communication node that maintains position without GNSS and to provide…

2 826 $

* price with VAT

Vishchun-M FPV Repeater for DJI Mavic

“Vishchun-M” is a compact aerial FPV repeater designed for integration with a DJI Mavic, extending communication range and stabilizing the video signal.

1 239 $

* price with VAT

Promin-10 Aerial Repeater

“Promin-10” is an integrated aerial repeater designed for stable transmission of video and UAV control signals from altitude without the use of GPS/GNSS.

2 284 $

* price with VAT

Aluminum Telescopic Mast

Telescopic mast is an aluminum mast designed for elevating antennas and repeaters to increase communication range and stability.

581 $

* price with VAT

484 $

* Price excluding VAT

FAQ

What is an aerial repeater?

An aerial repeater is a drone or module deployed in the air that transmits signals between the operator and the UAV, extending the control and video communication range.

What is an aerial repeater needed for?

An aerial repeater allows you to extend the flight range of an FPV drone, stabilize the video signal, and maintain control in challenging terrain.

What communication range does an aerial repeater provide?

Depending on the model and operating conditions, a stable video and control link can be maintained at distances of up to 15 km or more.

At what altitude does an aerial repeater operate?

The operating altitude depends on the model but can range from a few meters to several hundred meters, which improves line-of-sight signal quality.

Can the repeater be integrated with popular drones?

Yes, there are models that can be integrated with carrier drones or platforms such as the DJI Mavic for signal relaying.

How does an aerial repeater differ from a ground-based repeater?

An aerial repeater operates from altitude and improves line-of-sight signal conditions, whereas a ground repeater is installed on a mast or a fixed position.

How to choose an aerial repeater?

You should consider range, hovering altitude, autonomy, compatibility with the carrier drone, and operating frequencies.

Where can I buy an aerial repeater?

You can order aerial repeaters and receive a consultation through BlueBird Tech’s official communication channels.

What is a ground repeater?

A ground repeater is equipment that acts as an intermediate node between the operator and the drone. It receives the video signal and transmits control commands, extending the communication range. It amplifies the signal and improves connection stability, making drone control more convenient and reliable over long distances or in challenging conditions.

What is a ground repeater needed for?

A repeater allows you to increase flight distance and stabilize the video link with the UAV in challenging terrain conditions or in the presence of obstacles.

What is the operating range of a ground repeater?

Depending on the model and operating conditions, ground repeaters can provide stable communication with the drone at distances of up to 25 km.

Why is a mast needed for a repeater?

A mast allows the antenna to be raised to a height that improves signal quality and increases the range of stable communication.

Where can I buy a ground repeater station?

You can order ground repeater stations on the official BlueBird Tech website or through the contact channels listed there.

How to choose a ground repeater station?

The choice depends on the required range, the type of drone, operating frequencies, usage conditions, and the system format (mobile or stationary).
